Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-B380
| Voltage: | AC100V-240V 50/60HZ |
| Light source: | 380W lamp |
| Power consumption: | 450W |
| Channel: | 16CHs |
| Color: | 14 colors + open |
| Gobo: | 17 gobos + open |
| Strobe: | 0-10 times/second |
| Pan: | 540 degree+16 bit fine |
| Tilt : | 270 degree+16 bit fine |
| Display: | LCD display |
| Prism: | 16+48 facet prism can mix with the 6 colors wheel,Electronic focus, frost effect |
| N.W: | 20.5 KG |
| G.W: | 23.5 KG |
| Package size(1/CTN): | 48.5*48*72 CM |
Additional details:
Technical principle:
The 380W beam lamp generates a strong light beam through a high-power bulb, which is composed of a precise optical lens, and then realizes various lighting effects by rotating the lens and control system. The control system uses professional equipment or software to control the brightness, color and motion trajectory of the beam lamp.
Working principle:
1:High power lamp: Use 380 watt high power lamp as light source, produce high brightness white light.
2:Beam imaging: Light passes through an optical lens to form an image that focuses scattered light into a concentrated beam.
3:Lighting effects: By rotating lenses and filters and other equipment to achieve different colors, shapes and motion of the lighting effects.
4:Remote illumination: Using beam focusing and accurate control to achieve the illumination of distant targets.
Applications:
