Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-BY1240F
Video
| Voltage range: | AC100V-240V/50-60Hz |
| Rated power of the whole machine: | 550W |
| Light source: | 12 x 40W RGBW LED high-brightness imported lamp beads |
| Average life: | 50000h |
| Control mode: | DMX512, RDM, master-slave mode |
| Channel mode: | Built-in 2 channel modes 22CH/74CH (standard mode |
| Scanning system: | X stroke: 540° Y stroke 216° |
| Optical system: | high-precision combined integrated structure lens, high-transmittance quartz glass light rod + PMMA lens |
| Optical angle: | 5°～45° adjustable angle |
| Beam beam: | Small angle beam effect is outstanding |
| Wash dyeing: | medium and large angles to spread light evenly |
| Color: | RGBW color mixing system, uniform color mixing without flickering, fast color rainbow effect |
| Color temperature adjustable: | 2500～10000K |
| Effect macro: | static effect macro function and dynamic effect macro function |
| Strobe: | 1-25Hz electronic strobe and random multiple strobes |
| Dimming: | electronic dimming, 4 dimming modes |
| Zoom system: | Linear electric zoom |
| Front halo light strip: | can be controlled by a single point to chase the color-changing effect of flowing horse racing at will |
| Single circle control: | The light source supports independent control of color change in inner and outer single circles. |
| Single point control: | The light source supports individual independent control and color transformation |
| Display screen: | 1.77-inch OLED screen, Chinese and English bilingual menu, anti-interference photoelectric signal isolation system, waterproof smart touch keys |
| Intelligent management and control: | Through the lighting menu, you can check the equipment usage and lighting time, equipment temperature,Channel data and software version information, etc. |
| Temperature control: | Intelligent temperature control, which can automatically adjust the cooling fan speed and overheat protection |
| Software upgrade: | Upload upgrade files through DMX interface |
| Magnetic encoding positioning: | non-contact magnetic rotary encoder positioning, signal feedback, absolute position memory |
| Shell material: | The latest second generation structural waterproof design, metal die-cast aluminum shell and fireproof engineering plastic |
1:Music festival stage: Stage lighting used for large-scale open-air music festivals. Through its powerful beam output and all-round movement capabilities, it creates dazzling and shocking lighting effects for the music festival site and enhances the visual enjoyment of the audience.
2:Outdoor concerts: Suitable for outdoor music performances such as forest music festivals. Through waterproof and dustproof design and high-brightness light source, it provides professional lighting effects for outdoor concerts.
