Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-346T
| LED POWER: | 200W/300W |
| LED Color: | RGBW 4in1(200W), CW or WW (200W/300W) COB LED |
| Led Lamp: | Imported Led |
| Color Rendering Index(CRI): | Ra≥90 |
| LED Life Time: | over 50,000 hours |
| Voltage: | AC100-240V |
| Max.power : | 200W/300W |
| Zoom Functin: | Manual zoom |
| Beam Angle: | 12°to 30° or 25°to 50° |
| Focus: | Can be adjusted by hand |
| Iris: | optional |
| Housing: | Die-casting Aluminum |
| Dimming Curve: | 4 kinds |
| Dimming Frequency: | 500HZ - 25000HZ optional |
| Strobe : | 1-25times/sec |
| Technology: | High-quality optical system, glass aspherical |
| Touch screen: | LCD with touch screen |
| Control Protocol: | RDM / DMX |
| Control System: | DMX, Auto run and Master/Slave |
| DMX Channels: | 1/2CH(single color), 4/7(RGBW) |
| Working Temperature: | -10°C~40°C |
| Cooling System: | No noise fan (copper tube) |
| Thermal Sensor Monitoring: | Over-temperature Protection |
| IP Grade: | IP20 |
| Net Weight: | 11.46kgs(12-30 degree)11.05kgs(25-50 degree) |
| Gross Weight: | 14kgs |
| Packing Size: | 95.5*33*31.5 cm (12-30 degree)82*33*31.5 cm(25-50 degree) |
How to operate:
Connect AC power and turn on the light fixture's power switch.
Parameter setting and lighting adjustment via touch screen or DMX controller.
Adjust zoom and focus to get the desired beam effect.
Dimming and flashing frequency settings can be set as needed.
Precautions:
Do not use the lamp in high temperature or humid environments.
During operation and maintenance, be sure to disconnect the power supply to the lamp.
After long-term use, pay attention to the heat dissipation effect to ensure that the lamp works properly.
During use, avoid collisions and vibrations to avoid affecting the performance of the lamp.
Application:
Meeting/Event Venue:
This film and television light has a wide operating temperature range and a silent fan cooling system, making it suitable for lighting in conference venues and event sites. Its high-quality LED light source and dimming function can provide a comfortable lighting environment, and the IP20-rated design is also suitable for indoor conference and event venues, providing professional lighting support for various conferences, exhibitions, and celebrations.
Cinema/Theatre:
This film and television lamp has a high CRI value and multiple dimming curve options, suitable for the lighting needs of cinemas and theaters. Its dimming frequency and control protocol support can meet the detailed adjustment of lighting effects, provide suitable lighting atmosphere for stage plays, musicals and cinemas, and enhance the audience's viewing experience.
