Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-BY1915AZ
| Special Points. | 1. Each LED can be controlled individually. With unique honeycomb designed lens |
| 2. The front lens can rotate without limitation in forward and reverse direction to create amazing effects | |
| 3. Display screen can be turned upside down with 180°automatically to fit the installation in different place, Display can be equipped with rechargeable battery to set DMX address without power connection. | |
| 4. Can be used as beam, wash or effect light use (Kaleido effects) | |
| 5. The scanning position can be memory, it will be automatically reset without expected movement after rotation. | |
| 6. Fan cooling (fan will be change the speed with the temperature variation).Temperature detecting system (If the temperature detected error, the light will stop working to protect the fixture) | |
| 7. Fast speed with 3 phase motors on Pan and Tilt | |
| Voltage: | AC100V～240V 50-60HZ |
| Power: | 450W |
| LED Source: | 19x15W high power RGBW 4 in 1 LEDs Zoom: 4-60°Strobe: 0-20Hz |
| Tilt: | 270°+16 bit fine |
| Control Mode: | DMX512,Sound-actived,Master/slave |
| DMX Channels: | 21 CH/23 CH/35 CH/78 CH/92 CH/97 CH/99 CH |
| Dimmer: | 0-100% linear dimmer |
| Pan: | 540°+16 bit fine |
| Display: | LCD colorful display |
| IP: | IP20 |
| Fixture dimension: | 415*275*425 mm |
| Carton package Size: | 53*42*51CM (1pcs/ctn) |
| N.W: | 14.95 Kg |
| G.W: | 18.1Kg |
| Rechargeable Battery: | Optional Artnet: Optional |
Technical Principle
Using 19x15W high-power RGBW 4-in-1 LED light source, the zoom range is 4-60°, and the strobe range is 0-20Hz.
The horizontal scanning range is 270° + 16-bit accuracy, and the vertical scanning range is 540° + 16-bit accuracy.
Control modes include DMX512, voice control, master-slave mode, and the number of DMX channels ranges from 21 CH to 99 CH.
Linear dimming with a dimmable range of 0-100%.
Working Principle
By independently controlling the LED and rotating lens, as well as various control modes, various special effects and movements of the light can be achieved.
Utilize fan cooling and temperature detection systems to ensure stable operation of the equipment and avoid overheating damage.
Indoor sports event venues: used for lighting shows, award ceremonies and atmosphere creation during competitions.
Churches/Chapels: Provide flexible lighting effects for religious services and musical performances to enhance the ambience of religious sites
