Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-Mini680
| Input voltage: | AC100-240V, 50/60Hz |
| Rated power: | 950W |
| Light source: | 600W LED module |
| LED life: | 20,000 hours |
| Color temperature: | 6500K |
| Caliber: | 130mm Frontal lens for greater performance |
| Color rendering index: | Standard mode Ra>75, high CRI mode Ra>90 |
| Luminous flux: | 24000LM |
| Signal interface: | three-pin XLR (five-pin XLR optional) |
| Control mode: | DMX512, RDM, Auto Mode, master-slave, Sound activation |
| Channel mode: | 41CHs |
| Display system: | 2.8-inch touch LCD display, Chinese and English display, 180-degree rotation |
| Fixed color: | 6 colors + open position |
| Color mixing system: | independent CMY color mixing system |
| Color temperature adjustment: | independent CTO 2500K-7000K linear adjustment |
| Prisms: | Rotating 4-faced prism+6-faced linear prism, two prisms can be overlaid |
| Effect wheel: | dynamic effects such as stunning simulated dynamic flames, gurgling water, etc. |
| Fixed Gobo wheel: | 7 plug-in fixed gobos with an outer Rotating gobo Wheel: 8 gobos (pluggable), |
| Framing system: | 4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90° |
| Frost system: | 0~100% linear atomization |
| Iris system: | 6%~100% smooth adjustment |
| Beam Aperture: | 5°~50° fast motorized linear zoom |
| Dimming system: | 0-100% linear adjustment |
| Strobe system: | the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected |
| Pan: | 540° (16 bit precision scanning) |
| Tilt: | 270° (16 bit precision scanning) |
| Pan/Tilt: | Five-phase motor with magnetic encoding positioning function |
| Protection rate: | IP20 |
| Working environment: | 0-45℃ |
| Product net weight: | 30KG |
Additional details:
1:Concerts and performance venues: Mini680W LED BSWF MOVING PROFILE can be used in concerts, concerts and other performances to enhance the visual impact through its colorful lighting effects, create a spectacular stage atmosphere and enhance the audience's viewing experience.
2:Theater and stage play performances: In large theaters and stage play performances, this lamp can provide a variety of lighting effects for the stage, including color mixing, dynamic effects wheels and precise beam adjustment to match the plots of different plays and increase dramatic tension.
