Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-1000F
| Input voltage: | AC100-240V, 50/60Hz |
| Rated power: | 1050W |
| Light source: | 1000W LED module |
| LED life: | 20,000 hours |
| Color temperature: | 6500K |
| Caliber: | 150mm Frontal lens for greater performance |
| Color rendering index: | Standard mode Ra>75, high CRI mode Ra>90 |
| Luminous flux: | 32000LM |
| Signal interface: | three-pin XLR (five-pin XLR optional) |
| Control mode: | DMX512, RDM, Auto Mode, master-slave, Sound activation |
| Channel mode: | 36CHs |
| Display system: | 2.7-inch touch LCD display, Chinese and English display, 180-degree rotation |
| Fixed color: | 6 colors + open position |
| Color mixing system: | independent CMY color mixing system |
| Color temperature adjustment: | independent CTO 2800K-6500K linear adjustment |
| Prisms: | Rotating 3-faced prism+6-faced linear prism, two prisms can be overlaid |
| Effect wheel: | dynamic effects such as stunning simulated dynamic flames, gurgling water, etc. |
| Fixed Gobo wheel: | 11 plug-in fixed gobos with an outer diameter of 25.4mm+open position |
| Rotating gobo Wheel: | 7 gobos (pluggable), outer diameter 26.9mm, effective diameter 16.5mm, thickness 1.1mm+Open position |
| Framing system: | 4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90 |
| Frost system: | 0~100% linear atomization |
| Iris system: | 6%~100% smooth adjustment |
| Beam Aperture: | 5.5～~60～ fast motorized linear zoom |
| Dimming system: | 0-100% linear adjustment |
| Strobe system: | the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected |
| Pan: | 540～ (16 bit precision scanning) |
| Tilt: | 270～ (16 bit precision scanning) |
| Pan/Tilt | : Five-phase motor with magnetic encoding positioning function |
| Protection rate: | IP20 |
| Working environment: | 0-45⊥ |
| Product size: | 510*345*800(mm) |
| Carton size: | 730*690*590 (mm) |
| Product net weight: | 43KG |
| Product gross weight: | 51.5KG |
| Product appearance: | flame retardant, high temperature resistance, folding clamp |
Advantage:
1:High brightness: high luminous flux of 32000LM
2:Color performance: supports a variety of color effects and dynamic effects to meet different needs
3:Flexible control: supports multiple control modes, including DMX512, RDM, automatic mode, etc.
4:Multifunctional design: integrates a variety of special effects systems, such as prisms, dynamic wheels, etc., to display diverse lighting effects
5:Reasonable design: has good heat dissipation performance and structural design, suitable for long-term work
Application:
1:Film production: Used on film shooting scenes to add unique lighting effects to special effects shots and film scenes.
2:Large-scale music festivals: Suitable for outdoor music festivals and large-scale music events, presenting stunning stage visual effects to the audience.
