600W LED module DMX BSWF CMY CTO Profile Spot LED Framing Stage Light IP20

600W LED module DMX BSWF CMY CTO Profile Spot LED Framing Stage Light IP20

CMY CTO profile spot led

DMX BSWF profile spot led

CMY CTO LED Framing Stage Light

Place of Origin:


Brand Name:

Bright lighting


CE ISO9000

Model Number:


Contact Us
Request A Quote
Product Details
Light Source:
600W LED Module
Protection Rate:
LED Life:
20,000 Hours
Rated Power:
Input Voltage:
AC100-240V, 50/60Hz
Dimming System:
0-100% Linear Adjustment
Strobe System:
The Highest Frequency Can Reach 25Hz, And Random Strobe And Pulse Strobe Can Be Selected
Beam Aperture:
5°~50° Fast Motorized Linear Zoom
Payment & Shipping Terms
Minimum Order Quantity
1 Sets
Packaging Details
Carton Flightcase
Delivery Time
Payment Terms
T/T, Western Union, MoneyGram
Supply Ability
3000PCS per month
Product Description
Dmx Mini680W BSWF CMY-CTO Led Moving Head Profile Stage Light Beam Light
Input voltage: AC100-240V, 50/60Hz
Rated power: 950W
Light source: 600W LED module
LED life: 20,000 hours
Color temperature: 6500K
Caliber: 130mm Frontal lens for greater performance
Color rendering index: Standard mode Ra>75, high CRI mode Ra>90
Luminous flux: 24000LM
Signal interface: three-pin XLR (five-pin XLR optional)
Control mode: DMX512, RDM, Auto Mode, master-slave, Sound activation
Channel mode: 41CHs
Display system: 2.8-inch touch LCD display, Chinese and English display, 180-degree rotation
Fixed color: 6 colors + open position
Color mixing system: independent CMY color mixing system
Color temperature adjustment: independent CTO 2500K-7000K linear adjustment
Prisms: Rotating 4-faced prism+6-faced linear prism, two prisms can be overlaid
Effect wheel: dynamic effects such as stunning simulated dynamic flames, gurgling water, etc.
Fixed Gobo wheel: 7 plug-in fixed gobos with an outer Rotating gobo Wheel: 8 gobos (pluggable),
Framing system: 4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90°
Frost system: 0~100% linear atomization
Iris system: 6%~100% smooth adjustment
Beam Aperture: 5°~50° fast motorized linear zoom
Dimming system: 0-100% linear adjustment
Strobe system: the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected
Pan: 540° (16 bit precision scanning)
Tilt: 270° (16 bit precision scanning)
Pan/Tilt: Five-phase motor with magnetic encoding positioning function
Protection rate: IP20
Working environment: 0-45℃
Product net weight: 30KG



Additional details:

How to operate
Lighting parameter setting and stage effect adjustment through DMX512 controller or other compatible equipment
Parameter setting and status monitoring via LCD display

1:Large-scale indoor activities: such as celebrations, parties, award ceremonies and other large-scale indoor activities, Mini680W LED BSWF MOVING PROFILE can provide high-quality lighting effects for the event site, enhancing the atmosphere and visual impact.

2:Drama and dance performances: In theaters and dance performances, this lamp can provide colorful lighting effects according to different scenes and program needs, presenting a wonderful visual feast to the audience.


Provide after-sales service
