Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-B1240Z
| Special point: | 1. Built-in programs with macro effect. |
| 2. Each led is controllable individually | |
| 3. With 3 phase motor on pan and tilt to make fast movement. | |
| 4. Professional designed housing to fit professional market. | |
| Voltage: | AC90-240V 50-60HZ |
| Max Power: | 550 w |
| Source: | 12pcs 40w high brightness RGBW 4-in-1 leds |
| Dimmer: | 0-100% linear dimming system |
| Strobe: | 1-25 times/second |
| Pan: | 540°with 16 bit fine |
| Tilt: | 270° with 16 bit fine |
| Zoom: | 5-60°Smooth and fast zoom system |
| LED working lifetime: | Average 20,000 hours with low power consumption |
| Channel: | 19/67 two DMX channel mode |
| Control: | DMX512/master-slave/auto/sound |
| Color: | RGBW infinite mixture |
| Display: | LCD display |
| Fixture size: | 338 mm*264 mm*470 mm |
| N.W: | 14.2kg |
| Protection: | Auto temperature control system with big cooling fan,advanced cooling system |
Technical principles
This moving head light uses a high-brightness RGBW 4-in-1 LED light source, equipped with a 3-phase motor Pan and Tilt system as well as a linear dimming system and a fast zoom system. At the same time, it supports DMX512/master-slave/auto/sound multiple control methods.
working principle
The moving head light controls the color, brightness, flashing frequency and other parameters of the LED light source through built-in programs or external control signals, and realizes the positioning and movement of the light through the Pan and Tilt systems.
Entertainment venues: such as entertainment cities, amusement parks, etc., provide tourists with light shows and visual feasts.
Banquet/Party: For banquets or parties for private or business events, add lighting art elements to create an atmosphere.
Service:
Provide after-sales service
display:
Send your inquiry directly to us
