Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE
Model Number:
BR-Mini680
| Input voltage: | AC100-240V, 50/60Hz |
| Rated power: | 950W |
| Light source: | 600W LED module |
| LED life: | 20,000 hours |
| Color temperature: | 6500K |
| Caliber: | 130mm Frontal lens for greater performance |
| Color rendering index: | Standard mode Ra>75, high CRI mode Ra>90 |
| Luminous flux: | 24000LM |
| Signal interface: | three-pin XLR (five-pin XLR optional) |
| Control mode: | DMX512, RDM, Auto Mode, master-slave, Sound activation |
| Channel mode: | 41CHs |
| Display system: | 2.8-inch touch LCD display, Chinese and English display, 180-degree rotation |
| Fixed color: | 6 colors + open position |
| Color mixing system: | independent CMY color mixing system |
| Color temperature adjustment: | independent CTO 2500K-7000K linear adjustment |
| Prisms: | Rotating 4-faced prism+6-faced linear prism, two prisms can be overlaid |
| Effect wheel: | dynamic effects such as stunning simulated dynamic flames, gurgling water, etc. |
| Fixed Gobo wheel: | 7 plug-in fixed gobos with an outer Rotating gobo Wheel: 8 gobos (pluggable), |
| Framing system: | 4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90° |
| Frost system: | 0~100% linear atomization |
| Iris system: | 6%~100% smooth adjustment |
| Beam Aperture: | 5°~50° fast motorized linear zoom |
| Dimming system: | 0-100% linear adjustment |
| Strobe system: | the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected |
| Pan: | 540° (16 bit precision scanning) |
| Tilt: | 270° (16 bit precision scanning) |
| Pan/Tilt: | Five-phase motor with magnetic encoding positioning function |
| Protection rate: | IP20 |
| Working environment: | 0-45℃ |
| Product net weight: | 30KG |
Technical principle:
LED wash stage light uses LED light source to achieve color richness and change through mixing and modulation. Through the professional control system, the LED light source is dimmed, toning and other operations, so as to present different lighting effects
