Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE
Model Number:
BR-1000F
Working principle:
1:LED light source: LED light-emitting diodes generate high-brightness color light through current excitation.
2:Beam modulation: The LED light is diffused, focused or projected through the appropriate optical device to form the required beam shape and effect.
3:Color adjustment: By adjusting the brightness and color of the LED light source to achieve a variety of lighting effects, such as monochrome, multi-color mixing, color transformation, etc.
Our Services:
1 . We are professional led stage lighting factory for Thirteen years , technology in the industry is come out in
front.
2 . We have rich experience R&D engineer and we have strong ability for OEM projects.
3 . We have wee-trained and professional sales&after- sale services.
4 . For all your inquires about us or our products , we will reply you in detail within 24 hours.
5 . Our advantage are quick delivery , competitive price , high quality and long term service to our customer.
6 . There is as long- term cooperation with the shipping company , can make the goods more quickly and efficiently so that can delivered safely to the designated place.
| Input voltage: | AC100-240V, 50/60Hz |
| Rated power: | 1050W |
| Light source: | 1000W LED module |
| LED life: | 20,000 hours |
| Color temperature: | 6500K |
| Caliber: | 150mm Frontal lens for greater performance |
| Color rendering index: | Standard mode Ra>75, high CRI mode Ra>90 |
| Luminous flux: | 32000LM |
| Signal interface: | three-pin XLR (five-pin XLR optional) |
| Control mode: | DMX512, RDM, Auto Mode, master-slave, Sound activation |
| Channel mode: | 36CHs |
| Display system: | 2.7-inch touch LCD display, Chinese and English display, 180-degree rotation |
| Fixed color: | 6 colors + open position |
| Color mixing system: | independent CMY color mixing system |
| Color temperature adjustment: | independent CTO 2800K-6500K linear adjustment |
| Prisms: | Rotating 3-faced prism+6-faced linear prism, two prisms can be overlaid |
| Effect wheel: | dynamic effects such as stunning simulated dynamic flames, gurgling water, etc. |
| Fixed Gobo wheel: | 11 plug-in fixed gobos with an outer diameter of 25.4mm+open position |
| Rotating gobo Wheel: | 7 gobos (pluggable), outer diameter 26.9mm, effective diameter 16.5mm, thickness 1.1mm+Open position |
| Framing system: | 4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90 |
| Frost system: | 0~100% linear atomization |
| Iris system: | 6%~100% smooth adjustment |
| Beam Aperture: | 5.5～~60～ fast motorized linear zoom |
| Dimming system: | 0-100% linear adjustment |
| Strobe system: | the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected |
| Pan: | 540～ (16 bit precision scanning) |
| Tilt: | 270～ (16 bit precision scanning) |
| Pan/Tilt | : Five-phase motor with magnetic encoding positioning function |
| Protection rate: | IP20 |
| Working environment: | 0-45⊥ |
| Product size: | 510*345*800(mm) |
| Carton size: | 730*690*590 (mm) |
| Product net weight: | 43KG |
| Product gross weight: | 51.5KG |
| Product appearance: | flame retardant, high temperature resistance, folding clamp |
