Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-600F
| Input voltage: | AC100-240V, 50/60Hz |
| Rated power: | 900W |
| Light source: | 600W LED module |
| LED life: | 20,000 hours |
| Color temperature: | 6800K |
| Caliber: | 138mm Frontal lens for greater performance |
| Color rendering index: | Standard mode Ra>72, high CRI mode Ra>90 |
| Luminous flux: | 24000LM |
| Signal interface: | three-pin XLR (five-pin XLR optional) |
| Control mode: | DMX512, RDM, Auto Mode, master-slave, Sound activation |
| Channel mode: | 36CHs |
| Display system: | 2.7-inch touch LCD display, Chinese and English display, 180-degree rotation |
| Fixed color: | 6 colors + open position |
| Color mixing system: | independent CMY color mixing system |
| Color temperature adjustment: | independent CTO 2500K-7000K linear adjustment |
| Prisms: | Rotating 3-faced prism |
| Effect wheel: | dynamic effects such as stunning simulated dynamic flames, gurgling water, etc. |
| Fixed Gobo wheel: | 7 fixed gobos+open position |
| Rotating gobo Wheel: | 7 gobos (pluggable), outer diameter 22.9mm, effective diameter 16mm, thickness 1.1mm+Open position |
| Framing system: | 4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90° |
| Frost system: | 0~100% linear atomization |
| Iris system: | 5%~100% smooth adjustment |
| Beam Aperture: | 4.5°~50° fast motorized linear zoom |
| Dimming system: | 0-100% linear adjustment |
| Strobe system: | the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected |
| Pan: | 540° (16 bit precision scanning) |
| Tilt: | 270° (16 bit precision scanning) |
| Pan/Tilt: | Five-phase motor with magnetic encoding positioning function |
| Protection rate: | IP20 |
| Working environment: | 0-45℃ |
| Product size: | 424*286*770(mm) |
| Carton size: | 730*690*590 (mm) |
| Product net weight: | 35KG |
| Product gross weight: | 4.5KG |
| Product appearance: | flame retardant, high temperature resistance, folding clamp |
Technical principle
The framing light uses high-power LED modules as light sources, and achieves colorful lighting effects through independent CMY color mixing system and color temperature adjustment system. Equipped with a variety of dynamic effect modules and cutting systems, it can achieve precise beam control and diverse stage effects.
Working principle
The framing light receives external signals to control the lighting effects through various control modes such as DMX512, and adjusts the size, color, dynamic effects, etc. of the beam through built-in system modules and motors to achieve precise projection and rich changes of lights.
Stage performance: Cutting lights provide rich lighting effects and precise beam control, suitable for stage performances, concerts and other performing arts occasions.
Studio: In the studio, cutting lights can adjust the beam size, color and dynamic effects according to the needs of different programs to enhance the program effect
Company introduction
Guangzhou Bright Lighting Equipment Co.Ltd,
is a high-tech enterprise specializing in stage lighting equipment, lighting control systems, etc.integrating R&D, manufacturing, sales, and technical services. The company is located in Xinhua Industrial Zone, Huadu District, Guangzhou City.
Bright Lighting adhering to the corporate philosophy of quality survival and innovative development, continuously strengthens technology research and development and scientific innovation capabilities, strives for excellence and controls product quality, and provides partners with more high-quality products and technical solutions.
