Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-700F
| Input voltage: | AC100-240V, 50/60Hz |
| Rated power | 980W |
| Light source: | 700W LED module |
| LED life: | 20,000 hours |
| Color temperature: | 6800K |
| Caliber: | 138mm Frontal lens for greater performance |
| Color rendering index | Standard mode Ra>75, high CRI mode Ra>90 |
| Luminous flux: | 28000LM |
| Signal interface: | three-pin XLR (five-pin XLR optional) |
| Control mode: | DMX512, RDM, Auto Mode, master-slave, Sound activation |
| Channel mode: | 36CHs |
| Display system: | 2.7-inch touch LCD display, Chinese and English display, 180-degree rotation |
| Fixed color: | 7 colors + open position |
| Color mixing system: | independent CMY color mixing system |
| Color temperature adjustment: | independent CTO 2700K-7000K linear adjustment |
| Prisms: | Rotating 3-faced prism+6-faced linear prism, two prisms can be overlaid |
| Effect wheel: | dynamic effects such as stunning simulated dynamic flames, gurgling water, etc. |
| Fixed Gobo wheel: | 8 fixed gobos+open position |
| Rotating gobo Wheel: | 6 gobos (pluggable), outer diameter 27.9mm, effective diameter 16.5mm, thickness 1.1mm+Open position |
| Framing system: | 4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90° |
| Frost system: | 0~100% linear atomization |
| Iris system: | 5%~100% smooth adjustment |
| Beam Aperture: | 4.5°~50° fast motorized linear zoom |
| Dimming system: | 0-100% linear adjustment |
| Strobe system: | the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected |
| Pan | 540° (16 bit precision scanning) |
| Tilt: | 270° (16 bit precision scanning) |
| Pan/Tilt: | Five-phase motor with magnetic encoding positioning function |
| Protection rate: | Protection rate: |
| Working environment: | 0-45 |
| Product size: | 510*345*800(mm) |
| Carton size: | 730*690*590 (mm) |
| Product net weight: | 40KG |
| Product gross weight: | 48.5KG |
| Product appearance: | flame retardant, high temperature resistance, folding clamp |
Operation method and precautions
Please read the manual carefully before operation to ensure correct operation.
Please pay attention to the power supply voltage and working environment temperature range during use.
During operation, avoid excessive vibration or collision to avoid damage to the lamp.
Clean the surface of the lamp regularly to maintain the light output effect.
If there is a fault, please contact a professional for repair.
Lecture/Conference: Provide high-quality lighting effects to make speakers or hosts more prominent on the stage, attract the audience's attention, and enhance the professionalism and atmosphere of the meeting.
Dance performance: Dance performances require exquisite lighting effects to highlight the dancers' movements and emotions. Cutting lights can present a colorful dance scene on the stage through flexible color and light and shadow effects.
Company introduction
Guangzhou Bright Lighting Equipment Co.Ltd,
is a high-tech enterprise specializing in stage lighting equipment, lighting control systems, etc.integrating R&D, manufacturing, sales, and technical services. The company is located in Xinhua Industrial Zone, Huadu District, Guangzhou City.
Bright Lighting adhering to the corporate philosophy of quality survival and innovative development, continuously strengthens technology research and development and scientific innovation capabilities, strives for excellence and controls product quality, and provides partners with more high-quality products and technical solutions.
