Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-SP150
| Voltage: | AC100-240V,50-60Hz |
| Power: | 150W |
| Led source: | 100W White LED |
| Color Temperature: | 7500K-8000K |
| Led Life Time: | Average 50000 Hours |
| Channel: | 14 DMX channel |
| Control: | DMX/Master-slave/Auto/Sound activated |
| Pan: | 540 degree + fine Tilt: 270 degree + fine |
| Dimmer: | 0-100% smooth linear dimmer |
| Strobe: | 1-25 Hz with pulse effect |
| Beam angle: | 15 degree |
| Color Wheel: | 7 colors + open, |
| Static Gobo Wheel: | 7 gobos + open, with rotation and running water effect |
| Rotation gobo wheel: | 6 gobos+open |
| Prism: | 5 facet round prism |
| N.W: | 5.9 KG |
| G.W: | 7.2 KG |
| Package size: | 42*35*30 CM |
Working Principle
The working principle of the pattern moving head light is to receive external control signals (such as DMX signals) through the built-in electronic control system to control the color, brightness, movement and other parameters of the LED light source, thereby producing various lighting effects. At the same time, the optical system inside the lamp focuses, scatters or transforms the light beam into different shapes and patterns through precise design and adjustment.
Application:
Stage performances: Pattern moving lights are suitable for various performances on stage, such as concerts, dance performances and dramas, adding to the stage atmosphere through colorful lighting effects.
Studio: In studios such as TV stations, radio stations and recording studios, pattern moving lights can provide high brightness and diverse lighting effects to enhance the visual appeal of the program.
Service:
Provide after-sales service
Company introduction:
Guangzhou Bright Lighting Equipment Co.Ltd,
is a high-tech enterprise specializing in stage lighting equipment, lighting control systems, etc.integrating R&D, manufacturing, sales, and technical services. The company is located in Xinhua Industrial Zone, Huadu District, Guangzhou City.
Bright Lighting adhering to the corporate philosophy of quality survival and innovative development, continuously strengthens technology research and development and scientific innovation capabilities, strives for excellence and controls product quality, and provides partners with more high-quality products and technical solutions.
