Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE
Model Number:
BR-600F
| Input voltage: | AC100-240V, 50/60Hz |
| Rated power: | 900W |
| Light source: | 600W LED module |
| LED life: | 20,000 hours |
| Color temperature: | 6800K |
| Caliber: | 138mm Frontal lens for greater performance |
| Color rendering index: | Standard mode Ra>72, high CRI mode Ra>90 |
| Luminous flux: | 24000LM |
| Signal interface: | three-pin XLR (five-pin XLR optional) |
| Control mode: | DMX512, RDM, Auto Mode, master-slave, Sound activation |
| Channel mode: | 36CHs |
| Display system: | 2.7-inch touch LCD display, Chinese and English display, 180-degree rotation |
| Fixed color: | 6 colors + open position |
| Color mixing system: | independent CMY color mixing system |
| Color temperature adjustment: | independent CTO 2500K-7000K linear adjustment |
| Prisms: | Rotating 3-faced prism |
| Effect wheel: | dynamic effects such as stunning simulated dynamic flames, gurgling water, etc. |
| Fixed Gobo wheel: | 7 fixed gobos+open position |
| Rotating gobo Wheel: | 7 gobos (pluggable), outer diameter 22.9mm, effective diameter 16mm, thickness 1.1mm+Open position |
| Framing system: | 4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90° |
| Frost system: | 0~100% linear atomization |
| Iris system: | 5%~100% smooth adjustment |
| Beam Aperture: | 4.5°~50° fast motorized linear zoom |
| Dimming system: | 0-100% linear adjustment |
| Strobe system: | the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected |
| Pan: | 540° (16 bit precision scanning) |
| Tilt: | 270° (16 bit precision scanning) |
| Pan/Tilt: | Five-phase motor with magnetic encoding positioning function |
| Protection rate: | IP20 |
| Working environment: | 0-45℃ |
| Product size: | 424*286*770(mm) |
| Carton size: | 730*690*590 (mm) |
| Product net weight: | 35KG |
| Product gross weight: | 4.5KG |
| Product appearance: | flame retardant, high temperature resistance, folding clamp |
Working principle:
1:LED light source: LED light-emitting diodes generate high-brightness color light through current excitation.
2:Beam modulation: The LED light is diffused, focused or projected through the appropriate optical device to form the required beam shape and effect.
3:Color adjustment: By adjusting the brightness and color of the LED light source to achieve a variety of lighting effects, such as monochrome, multi-color mixing, color transformation, etc.
Matters needing attention:
1:Avoid using in high temperature and high humidity environment for a long time, so as not to affect the life of the lamp.
2:Clean the surface of lamps and cooling fans regularly to ensure smooth heat dissipation.
3:Check the fixed installation before use to ensure that the beam lamp is in a stable state.
