Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-B480
Video
| Features: | The latest third-generation motherboard, support RDM, display programming. With built-in program. |
| Voltage: | AC100V-240V, 50/60HZ |
| Light source: | OSRAM461 |
| Total power: | 800W |
| Beam angle: | parallel beam angle 1.9 degrees, linear dimming: independent dimming device, 0-100% linear dimming |
| High-speed strobe: | pulse strobe, strobe speed 1-20 times per second |
| Fixed color: | 1 fixed color wheel, including 13 color chips with white light, colorful effect, half color effect, linear color conversion and bidirectional variable speed rotating rainbow effect |
| Static pattern: | a fixed pattern plate, containing 14 patterns + 1 flowing pattern |
| Prism: | one sixteen prism and one (8+16+24) prism, prisms can be overlapped |
| Focusing: | high-precision glass optical lens, electronic linear high-definition adjustment |
| Atomization: | 1 independent atomization effect, the light spot is soft and natural |
| Colorful: | 1 independent seven-color rainbow effect |
| Color chip quality: | imported from Italy, special high temperature resistant raw materials, to achievestrong and bright vividness. |
| Horizontal/Vertical: | Horizontal scanning angle 540 degrees (16BIT precision scanning), vertical scanning angle 270 degrees (16BIT precision scanning) |
| XY Motor: | Three-phase motor. Three-phase motor drive, powerful, faster, smoother and quieter |
| Channel mode: | 18 international standard DMX512 channels |
| Beam diameter: | 165mm |
| Bulb function: | channel switch bulb and turn-on bulb function |
| Appearance: | High temperature resistant cast aluminum shell, adopts wind direction drainage and temperature intelligent monitoring technology |
| Protection level: | IP65 |
Production process and operation method
During the production process, high-temperature cast aluminum technology and high-quality raw materials are used to ensure that the product has good durability and stability. During operation, it is necessary to keep the equipment dry and clean to prevent water vapor and foreign matter from entering the interior of the lamp to ensure its long-term stable operation.
Control and scanning:
The horizontal scanning angle reaches 540 degrees, the vertical scanning angle is 270 degrees, 16-bit precision scanning is adopted, and high-performance three-phase motor is equipped to ensure smooth, accurate and low-noise operation.
Protection and design:
The protection level reaches IP65, the shell is made of high-temperature cast aluminum, and the design takes into account temperature monitoring and wind direction drainage technology to meet the use needs under various harsh environmental conditions.
Application:
Large events: It can be used for stage layout and lighting design of large events, such as exhibitions, celebrations, etc., to add atmosphere and visual effects to the venue.
Clubs and nightclubs: It is suitable for stage lighting effects in clubs and nightclubs, adding dynamics and live atmosphere to nightlife venues.
Service:
Provide after-sales service
Company introduction:
Guangzhou Bright Lighting Equipment Co.Ltd,
is a high-tech enterprise specializing in stage lighting equipment, lighting control systems, etc.integrating R&D, manufacturing, sales, and technical services. The company is located in Xinhua Industrial Zone, Huadu District, Guangzhou City.
Bright Lighting adhering to the corporate philosophy of quality survival and innovative development, continuously strengthens technology research and development and scientific innovation capabilities, strives for excellence and controls product quality, and provides partners with more high-quality products and technical solutions.
