Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-700F
Matters needing attention:
Weather Resistance: Ensure the light is designed for outdoor use and has appropriate weatherproofing to withstand various conditions.
Power Requirements: Verify the power supply requirements match your venue or event setup to prevent any electrical issues.
Durability: Check the build quality and materials used to ensure longevity and reliability, especially for outdoor environments.
Light Intensity and Range: Assess the brightness (lumens output) and the range of the light beam to meet the specific lighting needs of your event space.
Control Options: Understand the control interfaces available (DMX, wireless, etc.) and compatibility with your existing setup or control preferences.
Heat Dissipation: LEDs can generate heat; ensure the light has adequate cooling mechanisms to prevent overheating.
Mounting and Positioning: Consider the mounting options and flexibility in positioning the light for optimal coverage and effect.
Maintenance and Support: Check warranty details, availability of spare parts, and customer support for any potential issues or maintenance needs.
Regulations and Standards: Ensure the light complies with relevant safety regulations and standards for public events.
Specifications:
| Input voltage: | AC100-240V, 50/60Hz |
| Rated power | 980W |
| Light source: | 700W LED module |
| LED life: | 20,000 hours |
| Color temperature: | 6800K |
| Caliber: | 138mm Frontal lens for greater performance |
| Color rendering index | Standard mode Ra>75, high CRI mode Ra>90 |
| Luminous flux: | 28000LM |
| Signal interface: | three-pin XLR (five-pin XLR optional) |
| Control mode: | DMX512, RDM, Auto Mode, master-slave, Sound activation |
| Channel mode: | 36CHs |
| Display system: | 2.7-inch touch LCD display, Chinese and English display, 180-degree rotation |
| Fixed color: | 7 colors + open position |
| Color mixing system: | independent CMY color mixing system |
| Color temperature adjustment: | independent CTO 2700K-7000K linear adjustment |
| Prisms: | Rotating 3-faced prism+6-faced linear prism, two prisms can be overlaid |
| Effect wheel: | dynamic effects such as stunning simulated dynamic flames, gurgling water, etc. |
| Fixed Gobo wheel: | 8 fixed gobos+open position |
| Rotating gobo Wheel: | 6 gobos (pluggable), outer diameter 27.9mm, effective diameter 16.5mm, thickness 1.1mm+Open position |
| Framing system: | 4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90° |
| Frost system: | 0~100% linear atomization |
| Iris system: | 5%~100% smooth adjustment |
| Beam Aperture: | 4.5°~50° fast motorized linear zoom |
| Dimming system: | 0-100% linear adjustment |
| Strobe system: | the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected |
| Pan | 540° (16 bit precision scanning) |
| Tilt: | 270° (16 bit precision scanning) |
| Pan/Tilt: | Five-phase motor with magnetic encoding positioning function |
| Protection rate: | IP20 |
| Working environment: | 0-45 |
| Product size: | 510*345*800(mm) |
| Carton size: | 730*690*590 (mm) |
| Product net weight: | 40KG |
| Product gross weight: | 48.5KG |
| Product appearance: | : flame retardant, high temperature resistance, folding clamp |
Company introduction:
Guangzhou Bright Lighting Equipment Co.Ltd,
is a high-tech enterprise specializing in stage lighting equipment, lighting control systems, etc.integrating R&D, manufacturing, sales, and technical services. The company is located in Xinhua Industrial Zone, Huadu District, Guangzhou City.
Bright Lighting adhering to the corporate philosophy of quality survival and innovative development, continuously strengthens technology research and development and scientific innovation capabilities, strives for excellence and controls product quality, and provides partners with more high-quality products and technical solutions.
