Mini 380W Beam Moving Head Light Waterproof With CTO CMY Effect Spot BSW Wash Zoom

Mini 380W Beam Moving Head Light Waterproof With CTO CMY Effect Spot BSW Wash Zoom

Place of Origin:

China

Brand Name:

Brightlighting

Certification:

CE , ISO9000

Model Number:

BR-BSW380W

Contact Us
Request A Quote
Product Details
Dimmer:
0-100% Linear
Display:
CMY CTO
IP Rate:
IP65
Temperture:
-20℃~+40℃
Application:
For Your Stage Needs
High Power Output:
380 Watts Of Power
Payment & Shipping Terms
Minimum Order Quantity
5
Price
Negotiable
Packaging Details
Carton Package FlightCase
Payment Terms
T/T, Western Union, MoneyGram
Supply Ability
3000PCS
Product Description

Mini 380W Beam Moving Head Light Waterproof With CTO CMY Effect Spot BSW Wash Zoom



1. Description:

The Mini 380W Beam Moving Head Light is a versatile stage lighting fixture designed for professional use in various events and performances. Its waterproof design makes it suitable for both indoor and outdoor applications. It combines several advanced features including CTO (Color Temperature Orange), CMY color mixing, and multiple beam effects.

2. Specifications:

Specification Details
Light Source 380W High-Intensity LED
Beam Angle 2.5° (Beam mode)
Zoom Range 2.5° – 45° Adjustable Zoom
CTO (Color Temperature Orange) Yes, for adjustable color temperature from 3200K to 5600K
CMY Color Mixing Yes, for smooth color transitions and a wide color palette
Effects Spot, Beam, Wash (BSW)
Pan & Tilt Movement - Pan: 540° with 16-bit resolution
  - Tilt: 270° with 16-bit resolution
Dimming 0% - 100% with smooth dimming curve
Strobe Effect 1 - 25 flashes per second, with random strobe effects
Control Modes DMX512, Master/Slave, Auto, Sound-Activated
DMX Channels 14 / 16 channels
Control Protocol DMX512, RDM (Remote Device Management)
Display Screen LCD/LED Display with English menu for easy navigation
Power Supply AC 110V - 240V, 50/60Hz
Power Consumption Approximately 500W
Cooling System Temperature-controlled fan cooling system for efficient heat dissipation
Housing Durable aluminum alloy housing, waterproof rated IP65
Dimensions 400 mm x 290 mm x 570 mm (L x W x H)
Weight Approximately 15 kg
Mounting Options 360° mounting options with adjustable brackets


3. Detailed Features:

a. Light Source

  • LED Technology: Utilizes high-output 380W LED, offering a bright, sharp beam and long life.
  • Lamp Life: Typically around 20,000 hours or more.

b. Zoom and Beam Modes

  • Zoom Capability: Allows for a variable beam spread from a narrow 2.5° to a wide 45°, providing flexibility for different lighting effects.
  • Modes: Switch between Spot, Beam, and Wash modes for a range of lighting effects.

c. Color Effects

  • CTO Filter: Adjusts the color temperature from 3200K to 5600K, ideal for various lighting conditions.
  • CMY Color Mixing: Provides a smooth and seamless color mixing experience.

d. Motion

  • Pan and Tilt: Wide pan (540°) and tilt (270°) movement for dynamic light positioning.
  • Precision: 16-bit resolution for precise and smooth motion control.

e. DMX Control

  • Channels: Operates in 14 or 16 DMX channels for detailed control.
  • Modes: Supports DMX512 for professional control, along with Master/Slave and Sound-Activated modes for flexibility.

f. Effects and Strobe

  • Strobe Function: Adjustable strobe rate with options for different strobe effects.
  • Additional Effects: Includes various built-in effects for dynamic lighting designs.

g. Build Quality

  • Housing: Robust and waterproof housing ensures durability for outdoor events.
  • Cooling: Advanced cooling system prevents overheating during operation.

4. Applications:

  • Stage Productions: Perfect for theatrical performances and concerts.
  • Outdoor Events: Suitable for festivals, exhibitions, and outdoor performances.
  • TV and Film: Ideal for use in television and film productions due to its versatility and high-quality effects.

5. Maintenance and Care:

  • Cleaning: Regularly clean the lens and housing to maintain optimal performance.
  • Inspection: Check for any signs of wear or damage, especially to the moving parts and waterproof seals.











Mini 380W Beam Moving Head Light Waterproof With CTO CMY Effect Spot BSW Wash Zoom 0



Mini 380W Beam Moving Head Light Waterproof With CTO CMY Effect Spot BSW Wash Zoom 1

Mini 380W Beam Moving Head Light Waterproof With CTO CMY Effect Spot BSW Wash Zoom 2

Mini 380W Beam Moving Head Light Waterproof With CTO CMY Effect Spot BSW Wash Zoom 3

Mini 380W Beam Moving Head Light Waterproof With CTO CMY Effect Spot BSW Wash Zoom 4Mini 380W Beam Moving Head Light Waterproof With CTO CMY Effect Spot BSW Wash Zoom 5
