Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE
Model Number:
BR-FX1000
Specifications:
LED Type: 5050 1.5W RGB 3in1 LEDs
LED Count: 480
LED Colors: RGB
LED Segments: 20 (2 x 10)
Strobe Tube LEDs
LED Type: 3535 5W LEDs
LED Count: 144
LED Colors: Cool-White+Amber
LED Segments: 8+8
Resolution: 8-16 Bit
Tilt (Degrees): 185°
Control Modes: 10CH / 20CH / 77CH
Display: Illuminated graphic LCD
Protocol: USITT DMX-512, RDM
RDM: Bidirectional communication
Cooling: Temperature controlled, overheating protection
Dimmer: 0-100% electronic
Shutter: electronic, max. 20 Hz
Internal Effects: LED Macro Effects
Signal connection: XLR 5-Pin or 3-Pin In/Out
Power Input: PowerCON In/Out
Operating Conditions
Mains voltage: 100-240V AC / 50-60Hz
Power: 1000W
Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F
Operating Position: any
Mounting Options
Hanging: Omega-Bracket
Safety wire attachment: foldout eyelets
Shipping
Single fixture: cardboard
Tourpack: 4-way Flight Case
Housing Colors
Standard colors: black
Weight & Size
Size: 58x36x19cm (carton)
Weight: 10KG (carton)
Size: 94x50x49cm (4in1 flight case)
G.W.: 57KG (4in1 flight case)
Technical principle:
LED wash stage light uses LED light source to achieve color richness and change through mixing and modulation. Through the professional control system, the LED light source is dimmed, toning and other operations, so as to present different lighting effects
Company introduction:
Guangzhou Bright Lighting Equipment Co.Ltd,
is a high-tech enterprise specializing in stage lighting equipment, lighting control systems, etc.integrating R&D, manufacturing, sales, and technical services. The company is located in Xinhua Industrial Zone, Huadu District, Guangzhou City.
Bright Lighting adhering to the corporate philosophy of quality survival and innovative development, continuously strengthens technology research and development and scientific innovation capabilities, strives for excellence and controls product quality, and provides partners with more high-quality products and technical solutions
