12x40W RGBW LED Waterproof Moving Head Disco Lights Average Life 50000h

12x40W RGBW LED Waterproof Moving Head Disco Lights Average Life 50000h

12x40W waterproof moving head light

12x40W RGBW LED moving head disco lights

moving head disco lights 50000h

Place of Origin:


Brand Name:

Bright lighting


CE ISO9000

Model Number:


Contact Us
Request A Quote
Product Details
Rated Power Of The Whole Machine:
Voltage Range:
Shell Material:
The Latest Second Generation Structural Waterproof Design, Metal Die-cast Aluminum Shell And Fireproof Engineering Plastic
Magnetic Encoding Positioning::
Non-contact Magnetic Rotary Encoder Positioning, Signal Feedback, Absolute Position Memory
Control Mode:
DMX512, RDM, Master-slave Mode
Software Upgrade:
Upload Upgrade Files Through DMX Interface
Intelligent Management And Control:
Through The Lighting Menu, You Can Check The Equipment Usage And Lighting Time, Equipment Temperature,Channel Data And Software Version Information, Etc.
Optical System:
High-precision Combined Integrated Structure Lens, High-transmittance Quartz Glass Light Rod + PMMA Lens
Payment & Shipping Terms
Minimum Order Quantity
1 Sets
Packaging Details
Carton Flightcase
Delivery Time
Payment Terms
T/T, Western Union, MoneyGram
Supply Ability
3000PCS per month
Product Description
Waterproof Outdoor Moving Head Stage Light Wash Beam Light IP65 For The Show
Voltage range: AC100V-240V/50-60Hz
Rated power of the whole machine: 550W
Light source: 12 x 40W RGBW LED high-brightness imported lamp beads
Average life: 50000h
Control mode: DMX512, RDM, master-slave mode
Channel mode: Built-in 2 channel modes 22CH/74CH (standard mode
Scanning system: X stroke: 540° Y stroke 216°
Optical system: high-precision combined integrated structure lens, high-transmittance quartz glass light rod + PMMA lens
Optical angle: 5°~45° adjustable angle
Beam beam: Small angle beam effect is outstanding
Wash dyeing: medium and large angles to spread light evenly
Color: RGBW color mixing system, uniform color mixing without flickering, fast color rainbow effect
Color temperature adjustable: 2500~10000K
Effect macro: static effect macro function and dynamic effect macro function
Strobe: 1-25Hz electronic strobe and random multiple strobes
Dimming: electronic dimming, 4 dimming modes
Zoom system: Linear electric zoom
Front halo light strip: can be controlled by a single point to chase the color-changing effect of flowing horse racing at will
Single circle control: The light source supports independent control of color change in inner and outer single circles.
Single point control: The light source supports individual independent control and color transformation
Display screen: 1.77-inch OLED screen, Chinese and English bilingual menu, anti-interference photoelectric signal isolation system, waterproof smart touch keys
Intelligent management and control: Through the lighting menu, you can check the equipment usage and lighting time, equipment temperature,Channel data and software version information, etc.
Temperature control: Intelligent temperature control, which can automatically adjust the cooling fan speed and overheat protection
Software upgrade: Upload upgrade files through DMX interface
Magnetic encoding positioning: non-contact magnetic rotary encoder positioning, signal feedback, absolute position memory
Shell material: The latest second generation structural waterproof design, metal die-cast aluminum shell and fireproof engineering plastic


Additional details:
How to operate:
Parameters and trajectories can be adjusted through a dedicated control panel or software interface, and lighting can also be controlled through DMX control, automatic programs or music triggering.

1:Firm installation: When installing, you need to ensure that the device is firmly and reliably fixed on the bracket to avoid swinging or falling due to wind or other external forces
2:Electrical safety: Connect the power supply in strict accordance with electrical standards, ensure that the equipment is in good grounding and insulation condition, and prevent safety accidents caused by leakage.
3:Regular inspection: After long-term outdoor use, it is necessary to regularly check the waterproof and dustproof performance of the equipment and whether the connecting lines are intact, and perform timely maintenance.

1:Historical building lighting: Used to illuminate historical buildings at night. Through its diverse lighting effects and all-round movement, it gives the building a beautiful night scene effect.
2:City square lighting: Suitable for night lighting in city squares, commercial blocks and other places. Through its high brightness and various light effect modes, it adds a bright nighttime texture to the urban landscape.

Provide after-sales service
