Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-M3
| System: | Linux operating system |
| Touch screen: | Built-in 3 electric lifting 15.4-inch industrial full-view touch screen, 1 9-inch touch screen |
| Configuration: | powerful i5CPU, 4G memory, built-in solid state drive |
| DMX: | 6 DMX output ports, 1 composite DMX input port (can be set as output) |
| Connection: | Up to 65536 channels can be connected to the NPU |
| Button: | 30 electric replay faders with sensor function (60mm), 80 executive buttons |
| Control: | 1 total control putter • 1 dimming wheel |
| Trajectory ball: | 1 controllable XY axis high precision imported trackball |
| Electric push rod: | 2 A/B field electric push rods (100mm) |
| Coder: | 7 imported industrial grade wear-resistant encoders (with Push function) |
| Ethernet port: | 2 Gigabit Ethernet ports, support MA NET, ARTNET, etc. |
| USB port: | 5 USB ports, 1 backup USB port |
| Interface and display: | 2 work light interfaces,MIDI input and output interface,2 DVI interfaces, expandable two displays |
| Built -in and keyboard: | Built-in 2 drawers, built-in yellow backlit mechanical keyboard (backlight brightness adjustable) |
| Work power: | Wide-voltage industrial power supply 100V-240V 50/60Hz |
| Power: | Built-in high power UPS uninterruptible power supply |
| Function: | Support RDM function |
Technical Principles:
The light controller utilizes a Linux operating system and is equipped with a powerful i5CPU, 4G memory, and a built-in solid-state drive to ensure efficient operation and reliable performance. It features built-in touch screens, DMX output ports, DMX input port, electric replay faders, executive buttons, encoders, Ethernet ports, USB ports, DVI interfaces, MIDI input/output interface, and more, enabling seamless integration with a wide range of lighting fixtures and protocols.
Operating Principle:
The controller leverages its hardware and software capabilities to manage and control complex lighting configurations, offering users the ability to manipulate up to 65536 channels through intuitive user interfaces, faders, buttons, trackball, and other control elements. Its support for various protocols such as MA NET and ARTNET ensures compatibility with industry-standard lighting systems
Concerts and Music Festivals: The light controller is used to orchestrate dynamic lighting effects that synchronize with live performances, enhancing the visual impact of concerts and music festivals.
Theatrical Productions: It is employed in theatrical settings to manage the illumination of stage sets, create ambient lighting, and execute precise cues for scene transitions.
Service:
Provide after-sales service
Company introduction:
Guangzhou Bright Lighting Equipment Co.Ltd,
is a high-tech enterprise specializing in stage lighting equipment, lighting control systems, etc.integrating R&D, manufacturing, sales, and technical services. The company is located in Xinhua Industrial Zone, Huadu District, Guangzhou City.
Bright Lighting adhering to the corporate philosophy of quality survival and innovative development, continuously strengthens technology research and development and scientific innovation capabilities, strives for excellence and controls product quality, and provides partners with more high-quality products and technical solutions.
