Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-TIGER TOUCH II
Video
| Screen: | 14.1-inch screen |
| System: | 9.1 10.0 10.1 11.0 11.1 Five-system free switching system with ups power supply. |
| Output: | The default output is 4 512, the network can output 12 512 |
| Hardware: | Intel Core I5 processor, 120G solid state hard disk, 4GB running memory, 90 minutes ups power. |
| DMX: | Built-in 4 DMX output ports, 2048 channels;DMX outputs through the network |
| Support: | Support Art-net network output, which can be expanded to 12 Universe; Titan-net protocol, Support headphone output |
| Expandable: | expandable to 64 Universe DMX outputs |
| Faders: | 10 mechanical page turning playback faders; |
| Function keys: | 20 custom macro function keys |
| Built-in: | Built-in 14.1-inch highlight touch screen, which can be extended by a Titan Fader wing,20 playback faders, 30 custom macro functions, USB powered) |
| Interface: | 1 Gigabit network interface, support Art-net, Titan-net, Streaming CAN protocols,Compatible with other TITAN system console performance files |
| Carton size: | 59x54x36 |
| Carton weight: | 13.3KG |
| Air box size: | 59x54x29 |
| Air box weight: | 22.8Kg |
Advantage:
Multi-system switching and UPS power backup ensure the stability and reliability of the system.
The powerful DMX output capability and number of supported channels meet the needs of complex lighting control.
Supports network output and multiple protocols, enabling flexible connection and collaborative work with other devices.
The design of the touch screen and custom macro function keys simplifies the operation process and improves work efficiency.
It is highly scalable and can achieve more universe numbers, playback bars and customized macro functions by expanding the device.
Application:
Large event venues: such as stadiums, exhibition centers, etc., used to control lighting and special effects equipment, supporting multi-channel output and strong scalability.
Large hotels/banquet halls: Used to control the lighting effects of banquet halls, supporting customized macro function keys and touch screen operations to meet the needs of different scenarios.
Service:
Provide after-sales service
Company introduction:
Guangzhou Bright Lighting Equipment Co.Ltd,
is a high-tech enterprise specializing in stage lighting equipment, lighting control systems, etc.integrating R&D, manufacturing, sales, and technical services. The company is located in Xinhua Industrial Zone, Huadu District, Guangzhou City.
Bright Lighting adhering to the corporate philosophy of quality survival and innovative development, continuously strengthens technology research and development and scientific innovation capabilities, strives for excellence and controls product quality, and provides partners with more high-quality products and technical solutions.
