Place of Origin:
China
Brand Name:
Brightlighting
Certification:
CE
Model Number:
BR-W3715Z
Matters needing attention:
1:Avoid using in high temperature and high humidity environment for a long time, so as not to affect the life of the lamp.
2:Clean the surface of lamps and cooling fans regularly to ensure smooth heat dissipation.
3:Check the fixed installation before use to ensure that the beam lamp is in a stable state.
| Special point: | 1. With LED dimmer, scan position memory and auto reposition . |
| 2. Built-in programs with macro effect. | |
| 3. 37pcs LED with7 areas controllable effect to bring more amazing effect. | |
| 4. With 3 phase motor on pan and tilt to make fast movement. | |
| Voltage: | AC90-240V 50-60HZ |
| Max Power: | 600 w |
| Source: | 37pcs 15w high brightness RGBW 4-in-1 leds |
| Dimmer: | 0-100% linear dimming system |
| Strobe: | 1-25 times/second |
| Pan: | 540°with 16 bit fine |
| Tilt | :270° with 16 bit fine |
| Zoom: | 5-60°Smooth zoom system |
| LED working lifetime: | Average 50,000 hours with low power consuption |
| Channel: | 14/17/20/26/48 totally five DMX channel mode |
| Control: | DMX512/master-slave/auto/sound |
| Color: | RGBW infinite mixture |
| Display: | LCD display |
| Fixture size: | 386 mm*423 mm*263 mm |
| N.W: | 13.2 kg |
| Protection: | Auto temperature control system with big cooling fan,advanced cooling system |
Working principle:
1:LED light source: LED light-emitting diodes generate high-brightness color light through current excitation.
2:Beam modulation: The LED light is diffused, focused or projected through the appropriate optical device to form the required beam shape and effect.
3:Color adjustment: By adjusting the brightness and color of the LED light source to achieve a variety of lighting effects, such as monochrome, multi-color mixing, color transformation, etc.
Display:
