Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-MA2
Video
| System: | Linux operating system |
| Touch screen: | Built-in 2 electric lift 15.4 inch industrial full-view touch screen, 1 9-inch touch screen |
| Configuration: | powerful i5CPU, 4G memory, built-in solid state drive |
| DMX: | 6 DMX output ports, 1 composite DMX input port (can be set as output) |
| Connection: | Up to 65536 channels can be connected to the NPU |
| Button: | 15 electric replay faders with sensor function (60mm), 50 executive buttons |
| Control: | 1 total control putter • 1 dimming wheel |
| Trajectory ball: | 1 controllable XY axis high precision imported trackball |
| Electric push rod: | 2 A/B field electric push rods (100mm) |
| Coder: | 7 imported industrial grade wear-resistant encoders (with Push function) |
| Ethernet port: | 2 Gigabit Ethernet ports, support MA NET, ARTNET, etc. |
| USB port: | 5 USB ports, 1 backup USB port |
| Interface and display: | 2 work light interfaces,MIDI input and output interface,2 DVI interfaces, expandable two displays |
| Built -in and keyboard: | Built-in 2 drawers, built-in yellow backlit mechanical keyboard (backlight brightness adjustable) |
| Work power: | Wide-voltage industrial power supply 100V-240V 50/60Hz |
| Power: | Built-in high power UPS uninterruptible power supply |
| Function: | Support RDM function |
Technical principle and working principle: This device realizes user interaction and control through the Linux operating system and built-in touch screen interface. The DMX controller is connected to the lighting equipment through 6 output ports and 1 input/output port, supporting large-scale lighting control and programming. Various control elements such as electric faders, buttons, trackballs and encoders provide diverse operation methods and accuracy to meet the needs of different stage lighting effects.
Application:
Churches and auditoriums: Provides venue-appropriate lighting settings and control for religious ceremonies or concerts in churches and auditoriums.
Sports events: Lighting control for stadiums and event venues, providing visual support and enhancements for competitions, award ceremonies, etc.
Service:
Provide after-sales service
Company introduction:
Guangzhou Bright Lighting Equipment Co.Ltd,
is a high-tech enterprise specializing in stage lighting equipment, lighting control systems, etc.integrating R&D, manufacturing, sales, and technical services. The company is located in Xinhua Industrial Zone, Huadu District, Guangzhou City.
Bright Lighting adhering to the corporate philosophy of quality survival and innovative development, continuously strengthens technology research and development and scientific innovation capabilities, strives for excellence and controls product quality, and provides partners with more high-quality products and technical solutions.
