Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-MA2
Video
| System: | Linux operating system |
| Touch screen: | Built-in 2 electric lift 15.4 inch industrial full-view touch screen, 1 9-inch touch screen |
| Configuration: | powerful i5CPU, 4G memory, built-in solid state drive |
| DMX: | 6 DMX output ports, 1 composite DMX input port (can be set as output) |
| Connection: | Up to 65536 channels can be connected to the NPU |
| Button: | 15 electric replay faders with sensor function (60mm), 50 executive buttons |
| Control: | 1 total control putter • 1 dimming wheel |
| Trajectory ball: | 1 controllable XY axis high precision imported trackball |
| Electric push rod: | 2 A/B field electric push rods (100mm) |
| Coder: | 7 imported industrial grade wear-resistant encoders (with Push function) |
| Ethernet port: | 2 Gigabit Ethernet ports, support MA NET, ARTNET, etc. |
| USB port: | 5 USB ports, 1 backup USB port |
| Interface and display: | 2 work light interfaces,MIDI input and output interface,2 DVI interfaces, expandable two displays |
| Built -in and keyboard: | Built-in 2 drawers, built-in yellow backlit mechanical keyboard (backlight brightness adjustable) |
| Work power: | Wide-voltage industrial power supply 100V-240V 50/60Hz |
| Power: | Built-in high power UPS uninterruptible power supply |
| Function: | Support RDM function |
How to use:
Use the touch screen or yellow backlit mechanical keyboard for basic setup and control.
Select and adjust lighting effects with the motorized playback faders and buttons.
Use the trackball and encoder for precise position and parameter adjustments.
Data transfer and backup via network interface and USB port.
Application:
Conferences and exhibitions: Provide flexible lighting arrangement and control, support stage effects and atmosphere adjustment at conferences and exhibitions.
Theme parks and amusement parks: Used for night performances and light shows in theme parks, amusement parks and other places, creating unique visual effects to attract audiences.
Service:
Provide after-sales service
Company introduction:
Guangzhou Bright Lighting Equipment Co.Ltd,
is a high-tech enterprise specializing in stage lighting equipment, lighting control systems, etc.integrating R&D, manufacturing, sales, and technical services. The company is located in Xinhua Industrial Zone, Huadu District, Guangzhou City.
Bright Lighting adhering to the corporate philosophy of quality survival and innovative development, continuously strengthens technology research and development and scientific innovation capabilities, strives for excellence and controls product quality, and provides partners with more high-quality products and technical solutions.
