Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE
Model Number:
BR-7040Z
| Special Points. | 1. Each LED can be controlled individually. With unique honeycomb designed lens |
| 2. The front lens can rotate without limitation in forward and reverse direction to create amazing effects | |
| 3. Can be used as beam, wash or effect light use (Kaleido effects) | |
| Voltage: | AC100V～240V 50-60HZ |
| Power: | 320W |
| LED Source: | 7x40W high power RGBW 4 in 1 LEDs |
| Zoom: | 4-60° Strobe: 0-20Hz |
| Control Mode | : DMX512,Sound-actived,Master/slave |
| DMX Channels: | 23/35/51 three channel mode |
| Dimmer: | 0-100% linear dimmer |
| Pan: | 540°+16 |
| bit fine Tilt: | 220°+16 bit fine |
| Display: | LCDcolorful display |
| IP: | IP20 |
| Fixture dimension: | 347*246*438mm |
| Carton package Size: | 53*42*51CM (1pcs/ctn) |
| N.W: | 11.2 Kg |
Working principle:
1:LED light source: LED light-emitting diodes generate high-brightness color light through current excitation.
2:Beam modulation: The LED light is diffused, focused or projected through the appropriate optical device to form the required beam shape and effect.
3:Color adjustment: By adjusting the brightness and color of the LED light source to achieve a variety of lighting effects, such as monochrome, multi-color mixing, color transformation, etc.
