Place of Origin:
China
Brand Name:
Bright lighting
Certification:
CE ISO9000
Model Number:
BR-3715Z
Specifications:
| Special point: | 1. With LED dimmer, scan position memory and auto reposition . |
| 2. Built-in programs with macro effect. | |
| 3. 37pcs LED with7 areas controllable effect to bring more amazing effect. | |
| 4. With 3 phase motor on pan and tilt to make fast movement. | |
| Voltage: | AC90-240V 50-60HZ |
| Max Power: | 600 w |
| Source: | 37pcs 15w high brightness RGBW 4-in-1 leds |
| Dimmer: | 0-100% linear dimming system |
| Strobe: | 1-25 times/second |
| Pan: | 540°with 16 bit fine |
| Tilt | :270° with 16 bit fine |
| Zoom: | 5-60°Smooth zoom system |
| LED working lifetime: | Average 50,000 hours with low power consuption |
| Channel: | 14/17/20/26/48 totally five DMX channel mode |
| Control: | DMX512/master-slave/auto/sound |
| Color: | RGBW infinite mixture |
| Display: | LCD display |
| Fixture size: | 386 mm*423 mm*263 mm |
| N.W: | 13.2 kg |
| Protection: | Auto temperature control system with big cooling fan,advanced cooling system |
Features:
LED lamp design: 37 15W high-brightness RGBW 4-in-1 LED lamp beads are used to provide rich color mixing capabilities.
Dynamic effects: With LED dimmer, scan position memory and automatic repositioning functions, the continuity of the lamp effects can be maintained.
Built-in programs: Preset programs for multiple macro effects are built in, which is convenient for quickly calling different lighting performance effects.
Precise control: Pan (horizontal) and Tilt (vertical) movement controlled by 3-phase motors can achieve fast and accurate movement.
Technical principle:
The core technologies of Beeye Stage Light T include:
LED light source: Using high-performance RGBW LEDs, a wide range of lighting color adjustment capabilities are achieved through unlimited color mixing.
DMX control: Supports DMX512 protocol, which can be precisely synchronized and controlled with other lamps.
Automatic temperature control system: Equipped with advanced automatic temperature control system and large cooling fan to ensure long-term stable operation.
Application:
Outdoor events and festivals: Used in outdoor stages or festivals to adapt to different weather conditions and environmental requirements.
Conferences and large-scale events: Used for stage background lighting or focus lighting in conferences and large-scale events to increase the atmosphere of the scene.
Service:
Provide after-sales service
Display:
